365Beacon Spec Sheet
Updated

Purpose

This article serves as the spec sheet for the 365Beacon. It describes the Beacon's general product specifications and its POS terminal specifications






General Product Specification

  • Dimensions: 6.5mm height, 17mm length, 12 mm width
  • Weight: 0.067021 oz
  • Power Input: 3.6V Supply Min. | 5.5V Supply Max.
  • Environmental: Operating temp -40C to 85C (-40F to 121F)



POS Terminal Specification

  • Protocol / Class: Bluetooth 4.0 / Bluetooth Low Energy (BLE)
  • Output Power: 0 dBm
  • Data Rate: 100 kb/s
  • Receiver Sensitivity: -91 dBm
  • Frequency: 2.4 GHz
  • Modulation Technique: ATT, GAP, GATT, L2CAP
  • Range: 30 m
  • Antenna: Integrated
  • Interface Type: Serial
