PicoMarket Spec Sheet
Updated


General Product Specification

Dimensions H/W/L 470 mm / 200 mm / 340 mm ( 8.5 Inch / 7.9 Inch / 13.4 Inch )
Weight 6.4 Kg ( 14 lbs)
Power Input NAMA compliance
9 – 48 V DC wide range input (Typical 12V DC – 2A)
Environmental IP54 (Terminal Module front side only)
Recessed design
Anti-slip stand with counter mount option
Operating temp 0 – 40 C (32 – 104 F)



POS Terminal Specification

CPU / OS High performance MCU / Android 7.x and later
Display / Touch 5” TFT Color Display (1280 x 720) Capacitive Touch
Contactless Reader ISO14443 tpe A/B, ISO 18092
Mifare, Felica
VISA PayWave, MasterCard PayPass, AMEX ExpresPay, Discover D-PAS, Inerac Flash, CUP QuickPass, JCBJ J-speedy
MSR Reader Vertical Swipe
ICC at bottom Card insert upward
Front Camera 5 Megapixel
Communication 4G LTE (US band)
4G LTE Band 2,4,5,7,12,13,25,26
Need to meet AT&T criteria
Wi-Fi 802.11 a/b/g/n
Bluetooth 3.0
Ethernet RJ45
Antenna 4G: External / WiFi & Bluetooth internal integrated
Audio Speaker / Microphone / Audio Jack (4 pole)
Barcode Reader Newland EM2096 300 pixel projects bright red light beam
